   ElectroChemistry



















  Features & Benefits

 Multi-parameter Analyser

 - A high resolution graphic screen with white backlight  and Robust dust and splash-proof cabinet.

 - pH, mV, conductivity, ion, salinity, resistivity, TDS, dissolved oxygen,temperature, air pressure, rH2.

 - Free data acquisition software enables to view, store and edit the measurements in your computer.

 - Password protection prevents any unauthorised access to the instrument.

 - Storage memory for up to 12000 values + date and time.

 - Three year warranty  /  All necessary GLP-procedures are on board.



  Models



 Benchtop Multi-parameter analysers

C3010 • C3020 • C3030                                                     Broucher 보기

C3410 • C3420 • C3430                                                         Broucher 보기

2 independent channels for all measurements!

2 independent channels for all measurements!



pH: -2...+16 pH    mV: ± 2000 mV
Conductivity: 0...2000 mS/cm
Resistivity: 0...200 Mohm.cm
Salinity: 0.0...70.0
TDS: 0...100 g/l
Temperature: -5...+105°C
Resolution: 0.001 pH, 0.1 mV, 0.001 µS/cm,
1 ohm.cm, 0.01 mg/l, 0.1 ppt, 0.1°C




pH: -2...+16 pH       mV: ± 2000 mV
Ion: 0.01 ng/l...100 g/l /
C343x only
Dissolved oxygen: 0...60 mg/l
Conductivity: 0...2000 mS/cm
Resistivity: 0...200 Mohm.cm
Salinity: 0.0...70.0     TDS: 0...100 g/l
Temperature: -5...+105°C
Resolution: 0.001 pH, 0.1 mV, 0.001 µS/cm,
1 ohm.cm, 0.01 mg/l, 0.1 ppt, 0.1°C

C3040 • C3041                                                                Broucher 보기

C3050 • C3051 Bio-electronic analysers                                    Broucher 보기

6 independent channels for all measurements! (conductivity: only 2 channels)

3 independent channels for all measurements! (conductivity: only 2 channels)

pH: -2...+16 pH       mV: ± 2000 mV
Ion: 10-11...10+1, any unit
Conductivity: 0...2000 mS/cm
Resistivity: 0...200 Mohm.cm
Salinity: 0.0...70.0     TDS: 0...100 g/l
Dissolved oxygen: 0...60 mg/l, 0...600 %
Air pressure: 800...1100 hPa
Temperature: -5...+105°C
Resolution: 0.001 pH, 0.1 mV, 0.001 µS/cm,
1 ohm.cm, 0.01 mg/l, 0.1 ppt, 0.1°C

pH: 0...14 pH     mV: ± 2000 mV
rH2: 0...42 rH2
Conductivity: 0...2000 mS/cm
Resistivity: 0...200 Mohm.cm
TDS: 0...100 g/l
Salinity: 0.0...70.0
µW: 0...400000 µW
Temperature
: -5...+105°C
Resolution: 0.001 pH, 0.1 mV, 0.01 rH2, 0.001 µS/cm, 1 ohm.cm, 0.01 mg/l, 0.1 ppt, 0.1°C

C3060 • C3061                                                               Broucher 보기

C1010 • C1020                                                                   Broucher 보기

8 independent channels for all measurements! (conductivity: only 2 channels)

One pH/mV channel/ One conductivity/oxygen channel/ One temperature channel



pH: -2...+16 pH      mV: ± 2000 mV
Ion: 10-11...10+1, any unit
Conductivity: 0...2000 mS/cm
Resistivity: 0...200 Mohm.cm
Salinity: 0.0...70.0
TDS: 0...100 g/l
Temperature: -5...+105°C
Resolution: 0.001 pH, 0.1 mV, 0.001 µS/cm,
1 ohm.cm, 0.01 mg/l, 0.1 ppt, 0.1°C



pH: 0...14 pH     mV: ± 1000 mV
Conductivity: 0...100 mS/cm
Dissolved oxygen: 0...20 mg/l, 0...200 %
Temperature: 0...100°C
Resolution: 0.01 pH, 1 mV, 0.01 µS/cm,
0.01 mg/l (0.1%), 0.1°C






 Benchtop / Portable Multi-parameter analysers

C6010 • C6030                                                     Broucher 보기

One channel for all measurements!                                                          C6010                                                  C6030



pH: -2...+16 pH      mV: ± 2000 mV
Conductivity: 0...2000 mS/cm
Resistivity: 0...200 Mohm.cm
Salinity: 0.0...70.0
TDS: 0...100 g/l
Dissolved oxygen: 0...60 mg/l, 0...600%
Air pressure: 800...1100 hPa
Temperature: -5...+105°C
Resolution: 0.001 pH, 0.1 mV, 0.001 µS/cm,
1 ohm.cm, 0.01 mg/l, 0.1 ppt, 0.1°C

 C6010 +

Ion: 10-11...10+1, any unit



 Portable Multi-parameter analysers

C5010 • C5020                                                            Broucher 보기

C5030  Bio-electronic meter                                                   Broucher 보기

One pH/mV channel One conductivity/oxygen channel One temperature channel

One pH/mV channel One mV-H2/mV channel One temperature channel



pH: 0...14 pH
mV: ± 1000 mV
Conductivity: 0...100 mS/cm (C5020)
Dissolved oxygen: 0...20 mg/l, 0...200 %
Temperature: 0...100°C
Resolution: 0.01 pH, 1 mV, 0.1 µS/cm, 0.01 mg/l (0.1%), 0.1°C




pH: 0...14 pH
mV: ± 1000 mV
rH2: 0...42 rH2
Temperature: 0...100°C
Resolution: 0.01 pH, 1 mV, 0.1 rH2, 0.1°C







 Multi-parameter controllers

R3610 • R3620 • R3624                                               Broucher 보기

R3630                                                                        Broucher 보기

Two independent channels for all measurements

Two independent channels for all measurements + one free chlorine channel



pH: -2...+16 pH     mV: ± 2000 mV
Conductivity: 0...2000 mS/cm
Dissolved oxygen: 0..60 mg/l, 0..6 %
Air pressure: 800...1100 hPa
Temperature: -5...+105°C
Resolution: 0.001 pH, 0.1 mV, 0.001 µS/cm, 0.01 mg/l, 0.1 ppt, 0.1°C



pH: -2...+16 pH      mV: ± 2000 mV
Conductivity: 0...2000 mS/cm
Dissolved oxygen: 0...60 mg/l, 0...600 %
Air pressure: 800...1100 hPa
Free chlorine: 0...10 ppm
Temperature: -5...+105°C
Resolution: 0.001 pH, 0.1 mV, 0.001
 µS/cm, 0.01 mg/l, 0.1 ppt, 0.1°C



 Data loggers for pH - mV - Ion - Conductivity - Resistivity - TDS - Dissolved oxygen - Temperature

D230                                                                        Broucher 보기

4...28 pH/mV/Ion channels  / 4...28 conductivity channels   / 4...28 oxygen channels  / 4...28 temperature channels



D291
pH: 0...14 pH      mV: ± 2000 mV
Ion: 0.01 ng/l...99.9 g/l
Dissolved oxygen: 0...60 mg/l, 0...600%
Temperature: -30...+130°C
Resolution: 0.001 pH, 0.1 mV, 0.01 mg/l, 0.1°C

D292
Conductivity: 0...2000 mS/cm
TDS: 0...100 g/l
Temperature: -30...+130°C
Resolution: 0.01µS/cm, 0.01 mg/l,
0.1°C




 Electrodes               Broucher 보기







  Accessories



Electrode cables and accessories



AP414 Thermal printer                                                    Broucher 보기

SH300 Electrode holder                                              Broucher 보기



- Serial (RS232) and parallel (Centronix) input.
- Thermal dot matrix 9x320 dots.
- Prints 40 columns (normal) or 80 columns (condensed).
- Paper width: 112 mm.
- Roll length: ±28 m.
- For direct connection to all meters with a digital out-put.

Model SH300 holds up to three standard electrodes.

Its heavy base and very stable flexible arm allow the electrodes to move sideways or up and down while keeping them at a constant vertical angle.

 Buffer Solutions & memabranes                                      Broucher 보기

GOOD MEASUREMENT PRACTICES!



- All solutions are offered in sealed bottles.
- pH buffers are colour coded to reduce errors.
  They are certified to 0.02 pH.
- Conductivity standards are certified to 0.5 %.
- Redox standards are certified to 1 mV at 25°C.
- Each solution is supplied with a certificate.

Necessary solutions for ion selective electrodes
-
Calibration solutions         - ISA solutions
- Coloured buffers              - Redox standard solutions
- Electrolyte, 3M KCl           - Electrode cleaning solution

Spare parts for ion selective electrodes
- Replacement membrane kit   - Membrane filling solution
